Standard-type / flat dished head
Legend Standard-type/flat dished head
- t = wall thickness
- Do = outside diameter
- Di = inside diameter
- CR = crown radius
- KR = knuckle radius
- SF = straight flange height
- DH = dished height
- THi = total height inside
CR
Di (Standard-type dished head)
CR
1,3 x Di (Flat-type dished head)
KR
acc. to Di (15 - 50 mm)
SF
3,5 x t
DH
dished height
THi
SF + DH
