Hemispherical head
Legend Hemisperical head
- t = wall thickness
- Do = outside diameter
- Di = inside diameter
- CR = crown radius
- KR = knuckle radius
- SF = straight flange height
- DH = dished height
- THi = total height inside
Di
Do - 2 x t
CR
0,5x Di
SF
acc. to specification
DH
CRi
THi
SF + DH
