Diffuser head
Legend Diffuser head
- t = wall thickness
- Do = outside diameter
- Di = inside diameter
- CR = crown radius
- KR = knuckle radius
- SF = straight flange height
- DH = dished height
- THi = total height inside
CR
1,3 x Di
KR
15 - 50 mm acc. to Di
SF
3,5 x t
